BS En593 Cast Iron Semi Lug Type Worm Gear API609 Butterfly Valve
Basic Info
| Model NO. | D71X |
| Valve Core Material | Stainless Steel |
| Surface Treatment | Power Coating |
| Usage | Building |
| Media | Water, Sewage |
| Media Temperature | Low Temperature |
| Pressure | Low Pressure |
| Design | API609 |
| Structure | Butterfy |
| Operation | Manual, Pneumatic, Electric, Hydraulic |
| Rating | Pn10, ANSI 150lb, JIS 5K |
| Treatment | Powder Coating, Epoxy Coating |
| Seat Material | EPDM, PTFE, FKM, Nr |
| Accessories | Solenoid, Filter, Positioner on Request |
| Transport Package | Wood Case |
| Specification | 2"-48" |
| Trademark | TECHGEAR |
| Origin | China |
| HS Code | 8481804090 |
| Production Capacity | 350 Tons Per Month |
Product Description
BS EN593 Cast Iron Semi Lug Type Worm Gear API609 Butterfly Valve
Descriptions
Resilient Seated Butterfly Valve has rubber seat, unique shape, compact structure, high-strength disc using frame structure. It has bidirectional sealing function for installation without the interference of the medium flow direction. The surface is coated with epoxy resin, which could prevent rust effectively, a wide choice of seat material can be used in different medium, such as water, oil and gas.
Design BenefitsWafer /lug body available.Rated pressure 200 psi for size 2"-12"; 150 psi for 14"-16"Buna Seat up to 80 ºC; EPDM up to 100ºC.Stainless steel stemDisc: ductile iron-nickel plated; aluminum bronze or stainless steelPhenolic backed cartridge seat24", 36", 48", 60" & 72" extensionFusion bonded epoxy coatingMSS SP-67/ API609Installs between ANSI class125 /150 flangedTop flange: ISO5211
Material
| Part | Material |
| Body | Cast iron, ductile iron, carbon steel, AL-bronze, duplex stainless steel |
| Seat | NBR, EPDM, PTFE, Nature rubber, Viton, Hypalon |
| Stem | carbon steel, SS410, SS431, SS304, SS316, MONEL K500 |
| Disc | ductile iron, AL-bronze, duplex stainless steel, CF8, CF8M |
| Short bushing | PTFE |
| LONG bushing | PTFE |
| PIN | SS304, SS316, MONEL K500, duplex stainless steel |
| "O" ring | rubber |
| Size | A | B | C | D | E | F | G | H | J | K | L1 | L2 | M1 | N | Weight |
| 50 | 161.9 | 81 | 47.7 | 31.8 | 12.7 | 9.53 | 70 | 10 | 69.85 | 120.65 | 5/8-11 | 17.46 | 4 | 101.6 | 4.08 |
| 65 | 174.6 | 88.9 | 50.8 | 31.8 | 12.7 | 9.53 | 70 | 10 | 69.85 | 139.7 | 5/8-11 | 17.46 | 4 | 120.65 | 5.9 |
| 80 | 181 | 95.3 | 50.8 | 31.8 | 12.7 | 9.53 | 70 | 10 | 69.85 | 152.4 | 5/8-11 | 17.46 | 4 | 127 | 6.35 |
| 100 | 200 | 114.3 | 54 | 31.8 | 15.9 | 9.53 | 70 | 12 | 69.85 | 190.5 | 5/8-11 | 17.46 | 4 | 158.75 | 8.62 |
| 125 | 212.8 | 127 | 60.4 | 31.8 | 19.1 | 9.53 | 70 | 14 | 69.85 | 215.9 | 3/4-10 | 20.64 | 4 | 190.5 | 9.98 |
| 150 | 225.5 | 139.7 | 60.4 | 31.8 | 19.5 | 9.53 | 70 | 17 | 69.85 | 241.3 | 3/4-10 | 20.64 | 4 | 212.73 | 14.06 |
| 200 | 260.4 | 174.6 | 63.5 | 44.5 | 22.2 | 11.11 | 102 | 17 | 95.33 | 298.45 | 3/4-10 | 20.64 | 4 | 269.88 | 22.23 |
| 250 | 292.1 | 203.2 | 69.9 | 44.5 | 28.6 | 11.11 | 102 | 22 | 95.33 | 361.95 | 7/8-9 | 23.81 | 4 | 327.03 | 28.12 |
| 300 | 336.6 | 244.5 | 79.4 | 44.5 | 31.75 | 11.11 | 102 | 24 | 95.33 | 431.8 | 7/8-9 | 23.81 | 4 | 403.23 | 47.63 |
| 350 | 368.3 | 279 | 79.4 | 44.5 | 31.75 | 11.11 | 102 | 24 | 95.33 | 1-8 | 26.99 | 4 | 447.68 | 80.74 |
